C–2 HSG80 User’s Guide
Operator Control Panel LED Codes
Use Table C–1 to interpret solid OCP patterns and Table C–2 to
identify flashing OCP patterns. Note that in the ERROR column of
Table C-1, there are two separate descriptions. The first denotes the
actual error message that appears on your terminal, and the second
provides a more detailed explanation of the designated error. Use this
legend for both tables:
Note If the reset button is flashing and an LED is lit continuously,
either the devices on that LED’s bus don’t match the controller’s
configuration, or an error has occurred in one of the devices on that bus.
Also, a single LED that is lit indicates a failure of the drive on that port.
■ = reset button on
❏ = reset button off
● = LED on
❍ = LED off
