Figure 5–9 battery disable switch, Battery disable switch –49 – HP Array Controller HSG V8.7 Software User Manual
Page 245
Replacement Procedures
5–49
Figure 5–9 Battery Disable Switch
2. The batteries are no longer powering the cache module.
Note To return to normal operation, apply power to the storage
subsystem. The cache battery will be enabled when the subsystem is
powered on.
CXO6164A
Power
connector
Battery
disable
switch
Status
LED
ECB 1
ECB 2
