5–22 HSG80 User’s Guide
6. Enter option 1, Replace or remove a controller or cache module, from
the FRUTIL Main menu. FRUTIL displays the Replace or Remove
Options menu:
Replace or remove Options:
1. Other controller and cache module
2. Other controller module
3. Other cache module
4. Exit
Enter choice: 1, 2, 3, or 4 ->
7. Enter option 3, Other cache module, from the Replace or Remove
Options menu. FRUTIL displays the following:
Slot Designations
(front view)
[ --- EMU --- ][ --- PVA --- ]
[ -------- Controller A ------- ]
[ -------- Controller B ------- ]
[ Cache Module A ][ Cache Module B ]
Remove the slot A [or B] cache module? Y/N
8. Enter Y(es) and press return. FRUTIL displays the following:
Quiescing all device ports. Please wait...
Device Port 1 quiesced.
Device Port 2 quiesced.
Device Port 3 quiesced.
Device Port 4 quiesced.
Device Port 5 quiesced.
Device Port 6 quiesced.
All device ports quiesced.
Remove the slot A [or B] cache module within 2 minutes. Then
disconnect the external battery from the cache module.
Caution The device ports must quiesce before removing the cache
module. Failure to allow the ports to quiesce may result in data loss.
Quiescing may take several minutes.
ESD can easily damage the cache module. Wear a snug-fitting,
grounded ESD wrist strap.
