5–40 HSG80 User’s Guide
5. Enter N(o). FRUTIL displays the FRUTIL Main menu:
FRUTIL Main Menu:
1. Replace or remove a controller or cache module
2. Install a controller or cache module
3. Replace a PVA module
4. Replace an I/O module
5. Exit
Enter choice: 1, 2, 3, 4, or 5 ->
Note The HSG80 controller can support up to three enclosures. The
I/O Module status can show the following states: Single Ended – OK,
Differential – OK, Termination only – OK, Missing or bad, Unknown
or bad, or N/A (cabinet is not present).
6. Enter option 4, Replace an I/O module, from the FRUTIL Main menu.
In the following example, cabinet 0, port 5 is missing or bad. FRUTIL
displays the following:
I/O Module Status:
Cabinet 0 Cabinet 2 Cabinet 3
------------------- ------------------- -------------------
Port 1: Single Ended - OK N/A N/A
Port 2: Single Ended - OK N/A N/A
Port 3: Single Ended - OK N/A N/A
Port 4: Single Ended - OK N/A N/A
Port 5: Missing or bad N/A N/A
Port 6: Single Ended - OK N/A N/A
Is the replacement I/O module available? Y/N
7. Enter Y(es) and press return.
8. Wait for FRUTIL to quiesce the device ports. After the ports have been
quiesced (this may take several minutes), FRUTIL displays the
following:
All device ports quiesced.
Caution If you remove the incorrect module, the controller will crash.
9. Disconnect the cables (there may be one or two) from the appropriate
I/O module.
10. Remove the failed I/O module.
