Legacy Mobility 7131 Access Point (pre 4.x) version access points display just the power
mode.
2. Refer to the following to assess the access point’s current power state. Once known, determine
how available power resources are applied to the access point’s radios.
NOTE
Within the Power Configuration field, an installation professional selects a power mode based on the
different power resources available to that access point’s SKU. For 3af and 3at, choose between
Default and Option as best suited to that hardware SKU. For example, if Option is selected for 3af
Power, and the access point is a dual radio model, the following configuration is set:
LAN port ON (1000 BAST-T)
WAN port OFF
Radio 1 (2.4) on, 2x3 mode with maximum transmit power 18dBm
Radio 2 (5.0) on, 2x3 mode with maximum transmit power 18dBm
Contact Brocade Mobility Support if unsure of your access point’s optimal power management
settings.
