Viewing MU Statistics Summary
Use the MU Stats Summary screen to display overview statistics for mobile units (MUs) associated
with the Mobility 7131 Access Point. The MU List field displays basic information such as IP
Address and total throughput for each associated MU. The MU Stats screen is view-only with no
user configurable data fields. However, individual MUs can be selected from within the MU Stats
Summary screen to either ping to assess interoperability or display authentication statistics.
To view Mobility 7131 Access Point overview statistics for all of the MUs associated to the Mobility
7131 Access Point:
1. Select Status and Statistics - > MU Stats from the Mobility 7131 Access Point menu tree.
2. Refer to the MU List field to reference associated MU address, throughput and retry
information.
IP Address Displays the IP address of each of the associated MU.
MAC Address Displays the MAC address of each of the associated MU.
WLAN Displays the WLAN name each MU is interoperating with.
Radio Displays the name of the 802.11a/n or 802.11b/g/n radio each MU is associated with.
T-put Displays the total throughput in Megabits per second (Mbps) for each associated MU.
ABS Displays the Average Bit Speed (ABS) in Megabits per second (Mbps) for each associated
MU.
Retries Displays the average number of retries per packet. A high number retries could indicate
possible network or hardware problems.
Hotspot Displays whether this radio is currently supporting a hotspot.
