Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual
53
SAS/SATA Software Menus and Toolbars
Teledyne LeCroy
2.2.1
SAS Main Toolbar
The following figure displays the SAS main toolbar.
Figure 2.3: SAS: Software Menus and Toolbar
2.2.2
SATA Main Toolbar
The following figure displays the SATA main toolbar.
Figure 2.4: SATA: Software Menus and Toolbar
Open Project File
Launch Trainer
Launch Jammer
Abort Capturing Without Saving Sample File
Start Target Emulator
Find DUT
Upload Manager
Start Recording
Stop Target Emulator
Save
Stop Recording
Manual Trigger
Open Project File
Launch Trainer
Launch Jammer
Abort Capturing Without Saving Sample File
Start Device Emulator
Find DUT
Stop Recording
Upload Manager
Start Recording
Stop Device Emulator
Save
Manual Trigger
