Smart Commands (SATA only)
To enable smart commands, click the Settings tab to open the Settings dialog, click the
Advanced button to open the Advanced Target Setting dialog, go to the Miscellaneous
Feature tab, check Support smart feature set, and check the specific features to enable
them (see
“Miscellaneous Features Tab” on page 211 ).
Note about Payload Data file: The software refreshes the Payload Data file automatically,
so when you select a Payload Data file, you get the latest version.
For the SPC4 SEND DIAGNOSTIC command, if you have selected the non‐default path to
the development directory on the Software Settings page, that path is shown when you
select a Payload Data file.
Adding a User-Defined ATA Command
Click the Insert ATA Command button and choose User Defined. This enters an
ATA command line with editable fields to define your own custom command.
Figure 2.95: Insert ATA Command
Adding a SCSI Command (SAS only)
Click the Insert SCSI Command button, click one of the command categories, and choose
a command (see
Figure 2.95 on page 127 ).
