Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual 435
Sierra Trainer Generation Language Teledyne LeCroy
SATA Commands
Look at STP sample file for syntax.
 SEND_SATA_FRAME
 SendSATAFrame
 SATAData
 SATA_Data
 SATACRC
 SATA_CRC
 SATAXXXX
 SATA_XXXX
Primitive Commands
The following is a list of SAS and SATA primitives declared in Primitives.Decl.inc as Symbol
Chains. If you want to use these primitives in your script, you must also include
Primitives.Decl.inc in your script.
 SOF
 EOF
 SOAF
 EOAF
 ALIGN (0)
 ALIGN (1)
 ALIGN (2)
 ALIGN (3)
 NOTIFY (ENABLE SPINUP)
 NOTIFY (RESERVED 0)
 NOTIFY (RESERVED 1)
 NOTIFY (RESERVED 2)
 ACK
 NAK (CRC ERROR)
 NAK (RESERVED 0)
 NAK (RESERVED 1
 NAK (RESERVED 2)
 CREDIT_BLOCKED
set_trainer_interconnect_signal_1 or
settrainerinterconnectsignal_1 Set these signals to allow other ports to wait on
them using
WF_TRAINER_INTERCONNECT_SIGNAL_1
set_trainer_interconnect_signal_2 or
settrainerinterconnectsignal_2 Set these signals to allow other ports to wait on
them using
WF_TRAINER_INTERCONNECT_SIGNAL_2
set_trainer_interconnect_signal_3 or
settrainerinterconnectsignal_3 Set these signals to allow other ports to wait on
them using
WF_TRAINER_INTERCONNECT_SIGNAL_3
set_trainer_interconnect_signal_4 or
settrainerinterconnectsignal_4 Set these signals to allow other ports to wait on
them using
WF_TRAINER_INTERCONNECT_SIGNAL_4
