Teledyne LeCroy Sierra Trainer Generation Language
460 Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual
5.11.12 Assigning an Action
After you have dropped the Event button in a cell in the Main Display area, you can assign
an action to the event.
Note:
If you do not assign an action to an Event button, the Generator ignores the event.
To assign an action to an Event button:
1. Right‐click the Event button to display a pop‐up menu.
Figure 5.23: Action Menu
2. Select Specify Action, and then choose an action from the submenu. The menu
closes, and the action is assigned.
Figure 5.24: Action in Main Display
Note: You can also set actions within the Properties dialog for each event. Double‐click the Event
button to open the Properties dialog, then select the Actions tab and set your actions.
