Teledyne LeCroy SAS/SATA Software Menus and Toolbars
112 Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual
Protocol Analyzer
with Initiator
Emulator Port 1.
Pair on Port 1
One analyzer each on
Port 1 and Port 2.
One emulator each
on Port 1 and Port 2.
One analyzer each on
Port 1 and Port 3.
One emulator each
on Port 1 and Port 3.
One analyzer each on 
1 and 2, and
One emulator each
on 3 and 4.
One emulator each
on 1 and 2, and
One analyzer each on
3 and 4.
Pair on Port 1 and
pair on Port 2.
Pair on Port 1 and
pair on Port 3.
Pair on 1 and
one analyzer on 3 and
one analyzer on 4. NA
