Teledyne LeCroy Scenario Actions
358 Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual
TABLE 4.4: Test State Actions
Action Description
Analyzer
Trigger The Jammer sends a trigger to the Analyzer.
Beep Emits audible sound of duration selectable via
drop‐down list.
Branch to
Existing State
1 Go to a state in this sequence that is already
defined.
1
New State
1 Go to a state in this sequence that is not yet
defined (you need to define it).
1
Capture Data DWORD Captures a data DWORD into one of four registers.
Inject CRC Error Injects a CRC error into the line.
Invalid 10bit‐code
Error Injects invalid 10b code into the line.
Running Disparity
Error Injects a Running Disparity (RD) error into traffic.
Insert Address Frame
FIS Frame
SAS Primitive
SATA Primitive
SMP Frame
SSP Frame Inserts a frame or primitive.
Insert DWORD Inserts DWORD.
Link Disconnect Puts both InFusion SAS ports at electrical idle
immediately. This action is only in effect while the
scenario is running, and the Jammer will
reconnect the line when the scenario is stopped.
Reconnect Starts traffic pass‐through immediately. This
action restarts traffic after a previous disconnect
command. Once traffic is passing through, the
initiator and target resume OOB signaling.
Monitor/Count Opens a window to count the number of events
that occur during a session. A session is a time
interval during which a scenario runs.
Remove Frame Partially
Whole Frame Removes the targeted event from the traffic.In
InFusion.
A Remove primitive action is implemented by
replacing the primitive with an idle data DWORD.
A Remove frame action is implemented by
replacing the start‐of‐frame and end‐of‐frame
primitives with an idle data DWORD.
