Teledyne LeCroy
Target and Device Emulation
208
Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual
Media Settings
Enter a value for Average Access time to simulate Seek/Access time delay of a real
device.
Enter a Number of Areas. Define a Start and an End Address, click the down arrow under
the Area Type and choose Normal Writable, Circular Writable, or Non Writable.
Payload Size
Enter a value for Data Frame Payload Size in the General area.
Choose Target Emulator Port
Click a port option button and click the down arrow next to the Speed list box and choose
a port speed. Use the Speed Negotiation Setting button to open the dialog (see
“Speed
Negotiation Tab” on page 160
).
Note:
If you have made some changes to a defined emulation and want to return to the original
definition, check the Activate the emulator with old settings.
Ports Configuration
Click the Port Configuration button to display the Ports Configuration dialog (see
Device Activation
Enter number of times and period of activation.
Advanced Options
Click the Advanced button to display the OOB Signal Setting, Power Management setting,
Speed Negotiation, NCQ Command setting and Miscellaneous additional setting dialogs.
OOB Signal Setting
Edit the default values displayed in the white editable fields (see
).
