Teledyne LeCroy
Sierra Trainer Generation Language
446
Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual
Predefined Constants
WF_OPEN_RESPONSE
WF_OPEN_ACCEPT
WF_OPEN_REJECT
WF_ALIGN
WF_ALIGN_0
WF_ALIGN_1
WF_ALIGN_2
WF_ALIGN_3
WF_NOTIFY
WF_NOTIFY_ENABLE_SPINUP
WF_NOTIFY_RESERVED_0
WF_NOTIFY_RESERVED_1
WF_NOTIFY_RESERVED_2
WF_BROADCAST
WF_BROADCAST_CHANGE
WF_BROADCAST_RESERVED_0
WF_BROADCAST_RESERVED_1
WF_BROADCAST_RESERVED_2
WF_BROADCAST_RESERVED_3
WF_BROADCAST_RESERVED_4
WF_BROADCAST_RESERVED_CHANGE_0
WF_BROADCAST_RESERVED_CHANGE_1
WF_SAS_PS_REQ
WF_PS_REQ_PARTIAL
WF_PS_REQ_SLUMBER
WF_SAS_PS_STATUS
WF_PS_ACK
WF_PS_ACK
Predefined Constant
Internal Value
GEN_MODE_ERROR
0
GEN_MODE_SATA_HOST
1
GEN_MODE_SATA_DEVICE
2
GEN_MODE_SAS_INITIATOR
3
GEN_MODE_SAS_TARGET
4
GEN_LINK_SPEED_1_5G
00
GEN_LINK_SPEED_3G
01
GEN_LINK_SPEED_6G
10
SCRAMBLING_MODE_NONE
0
SCRAMBLING_MODE_SAS
1
SCRAMBLING_MODE_SATA
2
Wait Command Group
Group Contents
