Teledyne LeCroy Target and Device Emulation
210 Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual
Speed Negotiation
Click the Speed Negotiation tab to display the Speed Negotiation dialog. Specify Speed
Negotiating Error Option(s), Speed Negotiating Failure Option(s), Maximum
TRAIN_DONE pattern during MTT and a Speed Negotiation Failure Type. Check Pause
TRAIN scrambler on primitives.
Figure 2.204: Speed Negotiation Dialog
Power Management Settings Tab
The screen capture shows the Power Management Settings tab in the Advanced Target
Settings dialog (see
Figure 2.205 on page 209 ).
