Teledyne LeCroy SAS/SATA Software Menus and Toolbars
52 Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual
Exclude OOB Signals
Check this to exclude OOB signals from the data capture.
Exclude XXXX
Check this to exclude XXXX patterns from the data capture.
Note:
The validity of time stamps during Idles is traded off against good buffer memory utilization
when using ‘Exclude XXXX’.
Exclude Dev Slp Packets (SATA)
Check this to exclude Dev Slp Packets from the data capture.
Exclude Payload except
Check this to exclude Payload of Data Frames from the data capture. You can except a
number of DWORD(s). 
Note: The Data Report (refer to “Data Report” on page 250 ) does not reflect excluded Payload of Data
Frames.
Note:
When showing truncated data in the Data Payload View, the truncation points are marked with
a separator placed between payloads. You can get more information about the data exclusion
using the tooltip over the separator.
Exclude ALIGN
Check this to exclude ALIGN primitives from the data capture.
Exclude RRDY (SAS only)
Check this to exclude RRDY primitives from the data capture.
Exclude NOTIFY (SAS only)
Check this to exclude NOTIFY primitives from the data capture.
Exclude Idle
Check this to exclude Idles from the data capture.
Define different patterns for pre‐trigger and post‐trigger data captures
Replaces the Capture tab with a Pre‐Trigger Capture tab and a Post‐Trigger Capture tab.
2.2 SAS/SATA Software Menus and Toolbars
The SAS/SATA software has the following menus and toolbars.
Note: The sections “SAS Main Toolbar” on page 53 and “SATA Main Toolbar” on page 53 are shown
separately to indicate the different context sensitive toolbar options depending on whether SAS
or SATA trace or project is open.
