Port configuration depends on the application you run.
To act as analyzer, select the
Analyzer port configuration.
To activate a Device emulator on a port, select the
TargetEmulator port configuration.
To activate the Initiator Emulator on a port and run the Analyzer on the same
port, select
InitiatorEmulator/Analyzer.
To activate the InFusion on a port, select
Jammer.
To activate the Trainer on a port, select
Trainer.
Sierra M6‐4 can have Analyzer and Trainer or Analyzer and Jammer on the same port.
Note:
To display the current Port Configuration, click the green button in the lower right corner to
display the Port Status window (see
).
Port Configuration and Projects
Port Configuration depends on Project selected.
Performance Analyzer and Performance Analyzer with Initiator Emulator do not use
ports.
Protocol Analyzer, Protocol Analyzer with Initiator Emulator, and Target Emulator can
have the following port configurations.
Project
Number
One analyzer
and/or one emulator
Two analyzers
and/or two
emulators
Three analyzers
and optionally one
emulator
Four analyzers
or emulators
Protocol Analyzer Port 1.
One analyzer each on
1 and 2.
One each on
1, 2, and 3.
One each on
1, 2, 3, and 4.
