Sierra M6‐4 SAS/SATA Protocol Analyzer User Manual 421
Sierra Trainer Generation Language Teledyne LeCroy
# RawData with variables embedded
RawData {
K28.5 D24.0 D30.0 D01.4
@variableName1
50 00 62 B0
00 00 00 30
50 08 05 EF
$C
00 00 00 01
00 00 00 00
SendCRC
K28.5 D24.0 D07.3 D31.4 }
}
When there are variable values in RawData, you must include SendCRC command instead
of last dword. Otherwise, wrong CRC value will be sent. The constraints are:
 Variables are not allowed on First and LAST DWORD (instead of start/end
frames).
 SendCRC is only supported on last DWORD before end of frame.
Sending OpenAddressFrame Using
Standard Frame Templates Sending the Same
OpenAddressFrame Using Raw Data
Mechanism
SendOpenAddressFrameSTP {
SourceAddress = { 500805EF FFFF0041 }
DestinationAddress = { 500062B0 00000030
}
ArbitrationWaitTime = 0x1
AccessZoneManagement= 0x0
SourceZoneGroup = 0x0
ConnectionRate = 0x8
Features = 0x0
InitiatorConnectionTag = 0x1
InitiatorPort = 0x0
MoreCompatibleFeatures = 0x0
PathwayBlockedCount = 0x0
# CRC = 0x050F19E0 # good crc } Set ScramblingMode =
SCRAMBLING_MODE_SAS
RawData {
K28.5 D24.0 D30.0 D01.4
21 08 00 01
50 00 62 B0
00 00 00 30
50 08 05 EF
FF FF 00 41
00 00 00 01
00 00 00 00
05 0F 19 E0
K28.5 D24.0 D07.3 D31.4 }
* CRC is inserted manually
