Verex Director V4.9.1 User's Guide

21-0381E v4.9.1

Table 2: Arming station Tones

Condition

Standard Tones

Reverse Tones

Fire

3 times 500 ms on and off, then
there 1 second gap

Chime Double

short

125 ms on and 125 off four times

Double short :
125 ms on and 125 off four times

Exit/Entry Delay

Slow cadence: slow on/off tones
On Time: 250 ms
Off Time:750 ms

Steady continuous tone

Exit Delay with point open
(see note below)

Fast cadence: fast on/off tones
On Time: 250 ms
Off Time: 250 ms

Confirm Exit delay

Fast cadence: fast on/off tones:
On Time: 250 ms
Off Time: 250 ms

Trouble – Alarm,

Area Fail to Arm
(see note below)

Steady continuous tone

Slow cadence: slow tune on/off
tones:
On Time: 250 ms
Off Time:750 ms

Entry delay with
was/current in alarm

Fast cadence: fast on/off tones
On Time: 250 ms
Off Time: 250 ms

Area closing – 15 minutes

Double short tones:
125 ms on and 125 off four times.
Tones faster during last 5 minutes

Double short tones:
125 ms on and 125 off four times.
Tones faster during last 5 minute

Note: For conditions referencing this note, the tone will NOT be generated if the applicable area’s “Fail to Exit Mode” is
set to None/0 (zero).

Table 3: Buzzer via Output set to Follow Sonalert

Output Ref: Configuration, Output Points, […], ”Area, Area x, Sonalert…”)

Condition

Standard Tones

Reverse Tones

Fire

2 seconds on/off.

2 seconds on/off

Chime

1 second on

Exit/Entry Delay

1 second on two second off

Steady continuous tone

Exit Delay with point open
(see note below)

1 second on/off

Confirm Exit delay

1 second on/off:

1 second on/off

Trouble – Alarm,
Area Fail to Arm
(see note below)

Steady continuous tone

1 second on two second off

Entry delay with
was/current in alarm

1 second on/off:

1 second on/off

Area closing – 15 minutes

1 second on.
Tones faster during last 5 minutes

Note: For conditions referencing this note, the tone will NOT be generated if the applicable area’s “Fail to Exit Mode” is
set to None/0 (zero).
