 Inputs 
- Fire Required and Fire Circuit: Whether or
not the "Fire" input is being used, and the type
of circuit/wiring associated with it.
- Bypass Required and Bypass Circuit:
Whether or not the "Bypass" (manual
override) input is being used, and the type of
circuit/wiring associated with it. (Triggering
the bypass input enables the call button for all
floors for this elevator.)
- Panic Required and Panic Circuit: Whether
or not the "Panic" input is being used, and the
type of circuit/wiring associated with it. This
input triggers a "panic"-type of alarm.
- Floor Button to Enable: This identifies the
action to occur in the event of a fire (enable a
floor call-button, all floors, etc.).
 Floors 
- This screen lists all defined floors in the system.
Under "Control Access To", select the ones that
can be accessed from this elevator (lift) cab.
(i.e., that are physically connected.)
Tip: The floor relay board number/address, and relay
numbers are listed for your convenience.
Attention: Floors need to have been defined in the
same relative order as per the common relay-wiring
order for all elevator cabs (such as from lowest to
highest). To define system floors, refer to the floor
configuration topic (to follow).
 Desecure 
Cab Desecure Schedule
- Schedule: This is a schedule to determine the
times when an access card will be required to
use the floor call-buttons.
To define a schedule, refer to "Schedules for User
Access and Area Automation".
- Mode: Whether free access to floors is to be
provided inside or outside of schedule chosen
above (if applicable).
Communication Fail
- Fallback Mode: Cards to be granted access if
the elevator controller module is unable to
communicate with the main panel database:

None: No cards/tokens accepted;

Valid Token Format: All readable
cards/tokens accepted;
 Valid Site Code: All cards/tokens with the
correct site code will be granted access;

10 Fall-back Users: Only the users who are
assigned as 'FallBack Users'. For details,
refer to "Fall-Back Users...".
- Desecure on Comms Fail: Whether or not all
floor call-buttons are to be enabled whenever
the elevator controller or floor relay board has
lost communications.
- Relay Off When Desecure: This sets the
normal physical state of the floor selection
relays.
 = Relays normally powered (held open), and
powered down only when access to floors is allowed
(and during power failure);

= Relays normally de-energized (closed), and
energized only when access to floors is allowed. (No
floor access during power failure).
Wiring: Relays will typically be wired differently
based on this setting:

Requires COM – N/C wiring;
 Requires COM – N/O wiring.
Elevator controller floor selection relays must also be
wired to the floor call buttons in the same relative
order for all elevator (lift) cabs (such as from lowest to
highest accessed). The floors must then be entered in
the same order overall (such as from lowest to
highest). To set up floors, refer to the floor
configuration topic.
