344 Verex Director V4.9.1 User's Guide 21-0381E v4.9.1
Expansion / Application Modules: 24
system LCD keypads and/or other modules, or
60 suite-security keypads (see exceptions).
Exceptions: Suite-security keypads can be mixed with
other modules if desired (the capacity for suite-security
keypads is reduced by 5 for each system LCD keypad,
and each other expansion / application module added.
(For example, with 2 system keypads, 3 door
controllers, and one point expansion module, a full-
capacity "Enterprise" system could still support 30
suite-security keypads).
Converted TDC/PDC Door Controllers: Up to 10 per
panel (combined total).
Areas: 16 monitored 'areas' per panel;
Doors: The "Enterprise" version of the
software supports up to 32 doors per panel.
The "Prime" version supports a single panel
with 16 doors.
Note: To support doors/access-control, xL panels
(narrow mainboard), require a 'Feature Expansion
Board'.
Elevators: The "Enterprise" version of the
software supports up to 32 elevator (lift) cabs.
Exception: This is shared with the door capacity (max.
32 combined total).
Floors: The "Enterprise" version of the
software supports 124 unique access-
controlled floors.
(These can be in a single building,
or the combined total across multiple buildings.)
Monitored Sensors (Input Points):
(Depends on panel type, and number of point
expander modules.)
Up to 128: ISM panels (square mainboard).
Up to 256 (
V4.4): xL panels (narrow rectangular
mainboard).
Input Capacity Detail:
ISM (square mainboard): 128 (120 external to the
main panel). All of these can be wireless if keypads
are set to zero each.
xL (narrow mainboard): 256 (all can be external /
wireless if the main panel and keypads are set to 0
each).
Also See:
- Expansion Modules (
I/O tab, then "Inputs:")
- System Settings for each Panel ( I/O Mapping tab)
Programmable Outputs: 128 per panel.
Note: With ISM panels (square mainboard), outputs
005-008 are virtual outputs available only for use with
the numeric paging feature.
Expansion Module Capacities and Features
Inputs and Outputs
LCD
keypad
Suite
Keypad
Fire
module
MAP
annun.
RF
module
Door
ctrlr
I/O
expansion
Elevator
Controller
Inputs 1 8 / 4 / 2 8
class
A/B
4 32 8 8
16
0
Outputs 1 2 / 1 2 (8) 16 - 4 2 (10)
8 (16)
0
Supervision
LCD
keypad
Suite
Keypad
Fire
module
MAP
annun.
RF
module
Door
ctrlr
I/O
expansion
Elevator
Controller
Normally Closed   -     
Normally Open
with EOL   -     
Normally Closed with
EOL  - -     
Form C with EOL   -     
Dual EOL  - -     
Common Per-Panel Capacities (not based on 'Feature-Set')
