Page 110 LSI Corporation Confidential | July 2011
MegaRAID SAS Software User Guide Chapter 4: WebBIOS Configuration Utility | Creating a Storage Configuration
— Update Size: Click Update Size to update the Select size field value for the
selected RAID levels
NOTE: WebBIOS does not allow you to select 8 KB as the stripe size when you create a
RAID 60 drive group with six drives.
15. Click Accept to accept the changes to the virtual drive definition.
If you need to undo the changes, click the Reclaim button.
16. Click Next after you finish defining virtual drives.
The webBIOS Config Utility Config Wizard Configuration Preview dialog appears, as
shown in
Figure 59 .
Figure 59: RAID 60 Configuration Preview Dialog
17. Check the information in the Configuration Preview dialog.
18. If the virtual drive configuration is acceptable, click Accept to save the
configuration. Otherwise, click Back to return to the previous dialogs and change
the configuration.
19. If you accept the configuration, click Yes at the prompt to save the configuration.
The WebBIOS main menu appears.
