Commands 473
Parameters
The parameters for the command STIR are configured in the following dialog win-
dow:
• STIR
STIR - properties
Command name
25 characters, [ Stir # ]
Name of the command.
Device
Device name
Device name, [ not defined ]
Selection of a device from the device table. Only those devices being able
to execute the command are selectable. Additionally, not defined can be se-
lected. In this case, the device name must be assigned by the user at the
start of the method.
Device type
Device types, [ 814 USB Sample Processor ]
Display or selection of the device type. If a device is selected under Device
name , this parameter is not editable any more. The device type belonging to
the selected device is displayed instead.
If the option
not defined is selected as Device name , all device types being
able to execute the command can be selected independently from the de-
vices in the device table.
Stirrer
Stirrer
[ 1 ] ... 4 (Titrando, 730, 846)
[ T1 ], T2 (tower stirrer), 1...3 (MSB stirrer) (778, 789)
[ 1 ]...3 (814, 815)
1 (756, 831, Titrino)
Selection of the stirrer.
Stirrer type
801 magnetic stirrer, 802 Rod stirrer, 803 Ti Stand magnetic stirrer, 804 Ti Stand
rod stirrer, unknown
Display of the stirrer type. unknown is displayed either with devices unable
to read out the stirrer type or if no stirrer is connected.
