IC6 Operating Manual
10.4.6 Query General Parameter
Command = QG
Command ID = See Cmnd ID in
Table 10-6
Response = |
Description = Type of response depends on command ID, see Data Type column
in
Table 10-6 .
10.4.7 Update General Parameter
Command = UG
Command ID = See Table 10-6
Parameter Value = | Type of value depends on command ID,
see Data Type column in
Table 10-6 .
Response = None (Just header and trailer)
General Parameters :
Table 10-6 General parameters
QG UG
Cmd ID
Name
(Units)
Range:
Low
Limit/
High
Limit/
Default
Data Type
Notes
Update Restrictions
and Display Notes
1
(0x01)
Active Process 1/ 50/ 1 Integer Update not allowed if
process is running.
2
(0x02)
Layer To Start 1/ 200/ 1 Integer Cannot be greater than
number of layers in active
process.
If process change causes this
conflict, then value will be
changed to 1.
3
(0x03)
Run Number 1/ 9999/ 1 Integer
4
(0x04)
Auto Start Next 0/ 1/ 0 Encode 0 = No
1 = Yes
5
(0x05)
Max Concurrent
Layers
1/ 6/ 2 Integer Number of layers allowed
running simultaneously
6
(0x06)
Layers Displayed 0/ 2/ 0 Encode 0 = Auto
1 = 4 Layers
2 = 6 Layers
Gray Font if Max Concurrent
Layer is < 3
7
(0x07)
Not Used
