IC6 Operating Manual
10.2.2.2 How to Set Up the Network Protocol on the PC
Most personal computers (PC) are configured to obtain the IP address, an address
which defines the computer on the Internet, automatically from a server.
To communicate directly with the IC6, the Internet protocol (IP) on the PC must be
configured manually and an ethernet crossover cable (for example, IPN
600-1211-P5) must be connected between the PC and the IC6. Some PC’s will
auto-configure and work with either straight or crossover cable. Instructions are
provided here for manually configuring the Internet protocol.
NOTE: If the PC only has one ethernet port (that is, one network connection) then
setting the PC for direct communications will prohibit it from accessing the
Internet until that setting is reversed.
NOTE: These instructions will set two values—the IP address and the Subnet
mask—which will most likely prohibit access to the Internet. If these values
already contain information then this information should be recorded
somewhere for use in restoring the Internet connection.
To access the Network Connection on the PC, select Network Connections from
the Windows
® Start menu or from the Control Panel. See Figure 10-1 .
Figure 10-1 Accessing network connections
Select the Local Area Connection to be changed, right-click and select
Properties. See
Figure 10-2 .
Figure 10-2 Local area connection properties
