812 Multi-Service IronWare Routing Configuration Guide
53-1003033-02
Configuration examples
Syntax: backup [priority value] [track-priority value]
Syntax: track-port ethernet slot/portnum ve num
Syntax: ipv6-address ip-addr
Syntax: activate
VRRP-E example for IPv4
To implement the IPv4 VRRP-E configuration shown in Figure 41 on page 782, configure the VRRP
Routers as shown in the following sections.
Configuring router1
To configure VRRP Router1 in Figure 41 on page 782, enter the following commands.
Brocade(config)# router vrrp-extended
Brocade(config)# interface ethernet 1/6
Brocade(config-if-e10000-1/6)# ip address 10.53.5.2/24
Brocade(config-if-e10000-1/6)# ip vrrp-extended vrid 1
Brocade(config-if-e10000-1/6-vrid-1)# backup priority 110 track-priority 20
Brocade(config-if-e10000-1/6-vrid-1)# track-port ethernet 2/4
Brocade(config-if-e10000-1/6-vrid-1)# ip-address 10.53.5.254
Brocade(config-if-e10000-1/6-vrid-1)# activate
VRRP router 1 for this interface is activating
Brocade(config-if-e10000-1/6-vrid-1)# exit
Brocade(config)# interface ethernet 1/6
Brocade(config-if-e10000-1/6)# ip vrrp-extended vrid 2
Brocade(config-if-e10000-1/6-vrid-1)# backup priority 100 track-priority 20
Brocade(config-if-e10000-1/6-vrid-1)# track-port ethernet 2/4
Brocade(config-if-e10000-1/6-vrid-1)# ip-address 10.53.5.253
Brocade(config-if-e10000-1/6-vrid-1)# activate
VRRP router 2 for this interface is activating
NOTE
The address you enter with the ip-address command cannot be the same as a real IP address
configured on the interface.
NOTE
If VRRP is not configured globally, then you will see the response “Invalid input...” when you try to
create a VRRP instance.
Configuring router2
To configure Router2, enter the following commands.
Brocade(config)# router vrrp-extended
Brocade(config)# interface ethernet 5/1
Brocade(config-if-e10000-5/1)# ip address 10.53.5.3/24
Brocade(config-if-e10000-5/1)# ip vrrp-extended vrid 1
Brocade(config-if-e10000-5/1-vrid-1)# backup priority 100 track-priority 20
Brocade(config-if-e10000-5/1-vrid-1)# track-port ethernet 3/2
Brocade(config-if-e10000-5/1-vrid-1)# ip-address 10.53.5.254
Brocade(config-if-e10000-5/1-vrid-1)# activate
