Displaying BGP4+ information
Displaying BGP4+VRF6 neighbor information
To view BGP4+ configuration information about a specified VRF6’s neighbors, enter the following
command.
Syntax: show ipv6 bgp vrf vrf-name neighbors
The vrf-name parameter specifies the VRF6 name whose neighbor information needs to be
displayed.
Table 126 provides information about the command’s output.
TABLE 126 BGP4+ VRF6 neighbor information
This field... Displays...
IP Address The IP address of the neighbor.
AS The AS the neighbor is in.
EBGP or IBGP Whether the neighbor session is an IBGP session, an EBGP session, or
a confederation EBGP session:
•
EBGP – The neighbor is in another AS.
•
EBGP_Confed – The neighbor is a member of another sub-AS in
the same confederation.
•
IBGP – The neighbor is in the same AS.
RouterID The neighbor’s ID.
Brocade#show ipv6 bgp vrf abc neighbors
Total number of BGP Neighbors: 1
1 IP Address: 3:3:3::3, AS: 100 (IBGP), RouterID: 3.3.3.3, VRF: abc
State: ESTABLISHED, Time: 0h2m48s, KeepAliveTime: 60, HoldTime: 180
KeepAliveTimer Expire in 47 seconds, HoldTimer Expire in 120 seconds
Minimal Route Advertisement Interval: 0 seconds
UpdateSource: Loopback 1
RefreshCapability: Received
Messages: Open Update KeepAlive Notification Refresh-Req
Sent : 2 0 4 0 0
Received: 1 1 3 0 0
Last Update Time: NLRI Withdraw NLRI Withdraw
Tx: --- --- Rx: 0h2m48s ---
Last Connection Reset Reason:Unknown
Notification Sent: Unspecified
Notification Received: Unspecified
Neighbor NLRI Negotiation:
Peer Negotiated IPV6 unicast capability
Peer configured for IPV6 unicast Routes
Neighbor ipv6 MPLS Label Capability Negotiation:
Neighbor AS4 Capability Negotiation:
Outbound Policy Group:
ID: 2, Use Count: 2
BFD:Disabled
TCP Connection state: ESTABLISHED, flags:00000044 (0,0)
Maximum segment size: 1440
TTL check: 0, value: 0, rcvd: 63
Byte Sent: 121, Received: 205
