Configuring Inter-VRF routing
NOTE
Warning message will be displayed when import route is issued for non-existing VRF as follows: “VRF
vrf-name is not created yet”
NOTE
Warning message will be displayed when VRF is getting deleted by the user and exports routes to
other VRFs: “All IPv4 and IPv6 export routes in VRF one have been removed”
Show commands
Use the following commands to display the IPv4 and IPv6 routing configuration on the device and to
include the maximum allowed import VRFs.
Brocade# show ip
This command will display the maximum IPv4 allowed import VRFs and list of import VRFs to
default-vrf. The following is an example of this enhancement to show ip.
Brocade(config)#show ip
Global Settings
IP CAM Mode: static IPVPN CAM Mode: static
ttl: 64, arp-age: 10, bootp-relay-max-hops: 4, icmp-error-rate: 400
IP Router-Id: 10.0.0.1 load-sharing path: 4
enabled : UDP-Broadcast-Forwarding ICMP-Redirect ICMP-MPLS-Response
Source-Route Load-Sharing
RARP RIP BGP4 IS-IS OSPF VRRP
disabled: Directed-Broadcast-Forwarding drop-arp-pending-packets IRDP
Proxy-ARP RPF-Check RPF
-Exclude-Default VRRP-Extended VSRP
Configured Static Routes: 15
Maximum allowed import VRFs: 2048
Brocade
# show ipv6
This command will display the maximum IPv6 allowed import VRFs and list of IPv6 import VRFs to
default-vrf.
TABLE 65 Route-map for non-default & default VRF
This field... Displays
src-vrf The source VRF from where the routes have been imported to the destination
VRF. The "-" in the src-vrf column output denotes the route is local route.
import-map Route-map which has clauses to filter the routes coming from src-vrf.
Defaults By default no routes will be imported in to dest-vrf.
Range User can configure a maximum of 50 import commands for a given VRF per
address-family. If user tries to configure more than 50 commands then the
configuration will be rejected and an error message will be generated.
No The no command removes the configuration and all the routes imported from
src-vrf will be removed in the dest-vrf.
