Displaying IPv4 IS-IS information
Circuit Type
The type of IS-IS circuit running on the interface. The circuit type can be
one of the following:
•
BCAST (broadcast).
•
PTP (Point-to-Point)
Passive State
The passive state determines whether the interface is allowed to form an
IS-IS adjacency with the IS at the other end of the circuit. The state can
be one of the following:
•
FALSE – The passive option is disabled. The interface can form an
adjacency with the IS at the other end of the link.
•
TRUE – The passive option is enabled. The interface cannot form
an adjacency, but can still advertise itself into the area.
Circuit Number
The ID that the instance of IS-IS running on the interface applied to the
circuit between this interface and the interface at the other end of the
link.
MTU
The maximum length supported for IS-IS PDUs sent on this interface.
Level-1 Auth-mode
One of the following authentication modes set for Level-1 on the router:
•
None
•
md5
•
cleartext
Level-2 Auth-mode
One of the following authentication modes set for Level-2 on the router:
•
None
•
md5
•
cleartext
This parameter is not displayed for interfaces that are configured with a
Point-to-Point circuit type. This is because separate Level-2 Hello
messages are not sent on Point-to-Point interfaces. Consequently, "Hello
Interval", "Hello Multiplier", and "Authentication" parameters should
always be configured in the Level-1 mode for Point-to-Point interfaces.
Level-1 Metric
The default-metric value that the Brocade device inserts in IS-IS Level-1
PDUs for this interface.
Level-1 Priority
The priority of this IS to be elected as the Designated IS for Level-1 in this
broadcast network.
Level-1 Hello Interval
The number of seconds the software waits between sending Level-1
hello PDUs to the IS at the other end of the circuit.
Level-1 Hello Multiplier
The number by which the software multiplies the hello interval to
calculate the hold time set in Level-1 Hello PDUs sent on the circuit.
Level-1 Designated IS
The NET of the Level-1 Designated IS.
Level-1 DIS Changes
The number of times the NET of the Level-1 Designated IS has changed.
Level-2 Metric
The default-metric value that the Brocade device inserts in IS-IS Level-2
PDUs for this interface.
Level-2 Priority
The priority of this IS to be elected as the Designated IS for Level-2 in this
broadcast network.
Level-2 Hello Interval
The number of seconds the software waits between sending Level-2
Hello messages to the IS at the other end of the circuit.
TABLE 42
IS-IS interface information (Continued)
This field...
Displays...
