742 Multi-Service IronWare Routing Configuration Guide
53-1003033-02
IPv6 IS-IS Multi-Topology
Syntax: show ipv6 isis traffic
This display shows the following information.
IPv6 IS-IS Multi-Topology
IPv6 IS-IS supports Multi-Topology (MT) mode, which allows you to configure both IPv4 and IPv6
topologies on the router interfaces in an area or a domain. However, when implementing an MT, all
routers in an area (Level 1 routing) or a domain (Level 2 routing) can be configured with a set of
independent topologies on all their interfaces, even on loopback interfaces. All routers in an area
or a domain use the same type of IPv6 support, either single-topology or MT. In a network, the
Shortest Path First (SPF) is calculated for each configured topology.
Figure 37 depicts a non-congruent topology with IPv6 IS-IS MT enabled. Router 1 is an IPv4 and
IPv6 dual stack router, Router 2 is an IPv6 router, and Router 3 is an IPv4 router. All the routers
(Router 1, Router 2, and Router 3) in the Area 1 are configured with a set of independent
topologies.
TABLE 161 IPv6 IS-IS traffic statistics
This field... Displays...
Level-1 Hellos The number of Level-1 hello PDUs sent and received by the device.
Level-2 Hellos The number of Level-2 hello PDUs sent and received by the device.
PTP Hellos The number of point-to-point hello PDUs sent and received by the device.
Level-1 LSP The number of Level-1 link-state PDUs sent and received by the device.
Level-2 LSP The number of Level-2 link-state PDUs sent and received by the device.
Level-1 CSNP The number of Level-1 Complete Sequence Number PDUs (CSNPs) sent and
received by the device.
Level-2 CSNP The number of Level-2 CSNPs sent and received by the device.
Level-1 PSNP The number of Level-1 Partial Sequence Number PDUs (PSNPs) sent and received
by the device.
Level-2 PSNP The number of Level-2 PSNPs sent and received by the device.
