Displaying IPv6 IS-IS information
Metric: 10 IP-Extended 191.1.6.1/32 Up: 0 Subtlv: 0
Metric: 10 IP-Extended 192.68.1.0/31 Up: 0 Subtlv: 0
Metric: 10 IPv6 Reachablity 2000:56:1:0:0:1::/96 Up: 0 Subtlv: 0
Metric: 10 IPv6 Reachablity 2000:68:1:0:0:1::/96 Up: 0 Subtlv: 0
Metric: 10 IPv6 Reachablity 2000:1:1::6:1/128 Up: 0 Subtlv: 0
Metric: 10 IPv6 (MT-IPv6) 2000:56:1:0:0:1::/96 Up: 0 Subtlv: 0
Metric: 10 IPv6 (MT-IPv6) 2000:68:1:0:0:1::/96 Up: 0 Subtlv: 0
Metric: 10 IPv6 (MT-IPv6) 2000:1:1::6:1/128 Up: 0 Subtlv: 0
Metric: 10 IS (MT-IPv6) Dist2.12
Metric: 10 IS (MT-IPv6) Dist1.00
Metric: 10 IS-Extended Dist2.12
Metric: 10 IS-Extended Dist2.3a
Metric: 10 IS-Extended Dist1.00
LSPID Seq Num Checksum Holdtime ATT/P/OL
Dist2.12-00 0x00000009 0xe807 1100 0/0/0
Metric: 0 IS-Extended Dist2.00
Metric: 0 IS-Extended Core2.00
Syntax: show ipv6 isis database detail [l1 | l2 | level1 | level2]
The l1 and level1 options restrict the display to the level 1 LSP entries. You can use these options
interchangeably.
The l2 and level2 options restrict the display to the level 2 LSP entries. You can use these options
interchangeably.
For example, to display details about level 1 LSPs only, enter the following command at any CLI
level.
Brocade# show ipv6 isis database detail l1
describes the output parameters of the show ipv6 isis database detail command.
TABLE 154
Output parameters of the show ipv6 isis database detail command
Field
Description
LSPID
The LSP ID, which consists of the source ID (HHHH.HHHH.HHHH), the
pseudonode (HH-), and the LSPID (-HH).
NOTE: An asterisk (*) at the end of the address indicates that the LSP is
locally originated.
Seq Num
The sequence number of the LSP.
Checksum
The checksum calculated by the device that sent the LSP and used by the
device to verify that the LSP was not corrupted during transmission over the
network.
Holdtime
The maximum number of seconds during which the LSP remains valid.
NOTE: The IS that originates the LSP starts the timer for the LSP. As a result,
all LSPs do not have the same amount of time remaining when they
enter the device LSP database.
ATT/P/OL
A 4-bit value extracted from 4 through 7 bits in the Attach field of the LSP.
Area Address
The address of the area.
