764

Multi-Service IronWare Routing Configuration Guide

53-1003033-02

Configuring an IPv6 PBR policy

In the case of traffic incoming on the MPLS uplink, IPv6 PBR to VLAN flooding is only supported for
IPv6 traffic, and not for MPLS traffic.

There is no Layer 3 header processing. For example, in the case of an IPv6 packet header, the
hop-limit will not be decremented.

Table 168 describes the difference in behavior between different brocade products.

Enabling IPv6 PBR

After you configure the ACLs and route map entries, you can enable IPv6 PBR on individual
interfaces. To enable IPv6 PBR, you apply a route map you have configured for IPv6 PBR locally.

Enabling IPv6 PBR locally

To enable IPv6 PBR locally, enter the following commands:

Brocade(config)# interface ve 1

Brocade(config-vif-1)# ipv6 policy route-map test-route

The commands in this example change the CLI to the Interface level for virtual interface 1, and
then applies the “test-route” route map to the interface. You can apply an IPv6 PBR route map to
Ethernet ports or virtual interfaces.

Syntax: [no] ipv6 policy route-map map-name

Enter the name of the route map you want to use for the route map map-name parameter.

TABLE 168

VLAN flooding behavior differences

Scenario

Brocade NetIron CER and Brocade
NetIron CES

Brocade MLX Series and Brocade
NetIron XMR

Support for Switched Traffic

Not Supported (due to hardware
limitation)

Supported

If the outgoing-da option is not set. CES/CER: Packet floods with original

SA/DA

XMR/MLX:
Switched traffic:
Packet floods with original SA/DA
Routed traffic (L3 CAM miss):
Packet floods with original SA/DA
Routed traffic (L3 CAM hit):
Packet floods with original SA and DA
as next-hop MAC

If the outgoing-da option is set.

DA: Configured outgoing-da
SA: outgoing port MAC

DA: Configured outgoing-da
SA: Original SA

In Set next-hop-flood-vlan, if the
VLAN-ID is configured but no ports
are added or all ports are down.

Go to next set statement.

DROP matching packets.

Ingress VLAN and PBR Flood VLAN
are the same.

Packets are flooded back to source
port.

Packets are not flooded back to
source port.
