Multi-Service IronWare Routing Configuration Guide
135
53-1003033-02
Displaying BGP4 information
For information about the fields in this display, refer to
. The fields in this display also
appear in the show ip bgp display.
Displaying information for a specific route
To display BGP4 network information by specifying an IP address within the network, enter a
command such as the following at any level of the CLI.
Syntax: show ip bgp [route] ip-addr/prefix [longer-prefixes] | ip-addr
If you use the route option, the display for the information is different, as shown in the following
example.
These displays show the following information.
TABLE 11
BGP4 network information
This field...
Displays...
Number of BGP4 Routes matching
display condition
The number of routes that matched the display parameters you entered.
This is the number of routes displayed by the command.
Status codes
A list of the characters the display uses to indicate the route’s status.
The status code appears in the left column of the display, to the left of
each route. The status codes are described in the command’s output.
NOTE: This field appears only if you do not enter the route option.
Prefix
The network address and prefix.
Next Hop
The next-hop device for reaching the network.
Metric
The value of the route’s MED attribute. If the route does not have a
metric, this field is blank.
Brocade# show ip bgp 10.3.4.0
Number of BGP Routes matching display condition : 1
Status codes: s suppressed, d damped, h history, * valid, > best, i internal
Origin codes: i - IGP, e - EGP, ? - incomplete
Network Next Hop Metric LocPrf Weight Path
*> 10.3.4.0/24 192.168.4.106 100 0 65001 4355 1 1221 ?
Last update to IP routing table: 0h11m38s, 1 path(s) installed:
Gateway Port
192.168.2.1 2/1
Route is advertised to 1 peers:
10.20.20.2(65300)
Brocade# show ip bgp route 10.3.4.0
Number of BGP Routes matching display condition : 1
Status A:AGGREGATE B:BEST b:NOT-INSTALLED-BEST C:CONFED_EBGP D:DAMPED
E:EBGP H:HISTORY I:IBGP L:LOCAL M:MULTIPATH S:SUPPRESSED F:FILTERED
Prefix Next Hop MED
LocPrf Weight Status
1 10.3.4.0/24 192.168.4.106 100 0 BE
AS_PATH: 65001 4355 1 1221
Last update to IP routing table: 0h12m1s, 1 path(s) installed:
Gateway Port
192.168.2.1 2/1
Route is advertised to 1 peers:
10.20.20.2(65300)
