Page 334
306
Multi-Service IronWare Routing Configuration Guide
53-1003033-02
Displaying IPv4 IS-IS information
defines the fields shown in the above example output of the show ip ospf interface brief
command.
Displaying traffic statistics
The Brocade device maintains statistics for common IS-IS PDU types. To display the statistics, use
either of the following methods.
To display IS-IS PDU statistics, enter the following command at any level of the CLI.
Syntax: show isis traffic
This display shows the following information.
TABLE 46
Output of the show isis database summary command
This field
Displays
Number of LSPs
Total number of LSPs in database (includes those in the loading state).
Number of LSPs loading
Number of LSPs pending a full LSP update. This value is generally
non-zero during adjacency formation.
Number of LSP fragments
The number of LSPs with a non-zero LSP number (a fragment of an
LSP)
Number of Pseudo LSPs
The number of pseudo LSPs.
Number of Pseudo LSP fragments
The number of pseudo LSPs with a non-zero LSP number (a fragment of
an LSP).
Number of My LSPs
Total number of LSPs originated by this router.
Number of My LSP fragments
The number of LSPs originated by this router with a non-zero LSP
number (a fragment of an LSP)
Number of My Pseudo LSPs
The number of pseudo LSPs originated by this router.
Number of My Pseudo LSP
fragments
The number of pseudo LSPs originated by this router with a non-zero
LSP number (a fragment of an LSP).
Sum of LSPs Checksum
Total checksum of all LSPs in database (including those in loading
state). This number should be the same across ISIS routers during
periods of network stability.
TABLE 47
IS-IS traffic statistics
This field...
Displays...
Level-1 Hellos
The number of Level-1 hello PDUs sent and received by the Brocade device.
Level-2 Hellos
The number of Level-2 hello PDUs sent and received by the Brocade device.
Level-1 LSP
The number of Level-1 link-state PDUs sent and received by the Brocade device.
Brocade# show isis traffic
Message Received Message Sent
Level-1 Hellos 1029 115
Level-2 Hellos 1027 112
Level-1 LSP 6 3
Level-2 LSP 6 3
Level-1 CSNP 0 0
Level-2 CSNP 0 0
Level-1 PSNP 107 0
Level-2 PSNP 107 0
