Multi-Service IronWare Routing Configuration Guide
53-1003033-02
Displaying BGP4+ information
For example, to display detailed information about the best routes to a destination received from
neighbor 2001:db8::106, enter the following command.
This display shows the following information.
Status
The route’s status, which can be one or more of the following:
•
A – AGGREGATE. The route is an aggregate route for multiple networks.
•
B – BEST. BGP4+ has determined that this is the optimal route to the
destination.
•
C – CONFED_EBGP. The route was learned from a neighbor in the same
confederation and AS, but in a different sub-AS within the confederation.
•
D – DAMPED. This route has been dampened (by the route dampening
feature), and is currently unusable.
•
E – EBGP. The route was learned through a in another AS.
•
H – HISTORY. Route dampening is configured for this route, and the route
has a history of flapping and is unreachable now.
•
I – IBGP. The route was learned through a in the same AS.
•
L – LOCAL. The route originated on this device.
•
M – MULTIPATH. BGP4+ load sharing is enabled and this route was
selected as one of the best ones to the destination. The best route among
the multiple paths also is marked with “B”.
NOTE: If the “m” is shown in lowercase, the software was not able to install
the route in the IPv6 route table.
•
S – SUPPRESSED. This route was suppressed during aggregation and
thus is not advertised to neighbors.
•
F – FILTERED. This route was filtered out by BGP4+ route policies on the
device, but the saved updates containing the filtered routes.
AS-PATH
The AS-path information for the route.
TABLE 119
Detailed best and unreachable routes from a BGP4+ neighbor
This field...
Displays...
Number of accepted routes from a
specified neighbor (appears only in display
for all routes)
For information about this field, refer to
Status codes
For information about this field, refer to
Prefix
For information about this field, refer to
Status
For information about this field, refer to
TABLE 118
Summary of best and unreachable routes from a BGP4+ neighbor (Continued)
This field...
Displays...
Brocade# show ipv6 bgp neighbor 2000:4::106 routes detail best
There are 2 accepted routes from neighbor 2000:4::106
Searching for matching routes, use ^C to quit...
Status A:AGGREGATE B:BEST b:NOT-INSTALLED-BEST C:CONFED_EBGP D:DAMPED
E:EBGP H:HISTORY I:IBGP L:LOCAL M:MULTIPATH S:SUPPRESSED F:FILTERED
1 Prefix: 2001:db8::/32, Status: BE, Age: 18h48m56s
NEXT_HOP: 2001:db8::106, Learned from Peer: 2001:db8::106 (65001)
LOCAL_PREF: 100, MED: 1, ORIGIN: incomplete, Weight: 0
AS_PATH: 65001
2 Prefix: 2001:db8:1234::/48, Status: BE, Age: 18h48m56s
NEXT_HOP: 2001:db8::106, Learned from Peer: 2001:db8::106 (65001)
LOCAL_PREF: 100, MED: 1, ORIGIN: incomplete, Weight: 0
AS_PATH: 65001
