Displaying OSPFv3 information
Displaying IPv6 interface information
You can use the following command to display a summary of IPv6 Interface information.
Brocade# show ipv6 interface
Type Codes - I:ISIS O:OSPF R:RIP
Interface Stat/Prot IGPs IPv6 Address VRF
eth 3/20 up/up fe80::2c0:12ff:fe34:5073 default-vrf
2001:db8:1000::1/64
2001:db8:1000::/64[Anycast]
Syntax: show ipv6 interface [ ethernet port | loopback number | tunnel number | ve number ]
The ethernet | loopback | tunnel | ve parameter specifies the interface for which to display
information. If you specify an Ethernet interface, also specify the port number associated with the
interface. If you specify a loopback, tunnel, or VE interface, also specify the number associated
with the interface.
This display shows the following information.
Prefix Options An 8-bit field of capabilities that serve as input to various routing calculations:
•
NU – The prefix is excluded from IPv6 unicast calculations.
•
LA – The prefix is an IPv6 interface address of the advertising router.
•
MC – The prefix is included in IPv6 multicast routing calculations.
•
P – NSSA area prefixes are readvertised at the NSSA area border.
Prefix The IPv6 prefix included in the LSA.
Intra-Area Prefix LSAs (Type 9) (Iap) Fields
Number of Prefix The number of prefixes included in the LSA.
Referenced LS Type,
Referenced LS ID Identifies the router-LSA or network-LSA with which the IPv6 address prefixes are
associated.
Referenced Advertising
Router The address of the neighboring router that advertised the route.
Prefix Options An 8-bit field describing various capabilities associated with the prefix.
Metric The cost of using the advertised prefix.
Prefix The IPv6 prefix included in the LSA.
Number of Prefix The number of prefixes included in the LSA.
TABLE 134 Summary of IPv6 interface information
Field Description
Type Codes Shows the routing protocol enabled on the interface. The routing protocol can be
one of the following:
•
R – RIP
•
O – OSPF
•
I – IS-IS
Interface Shows the type, slot, and port number of the interface.
TABLE 133 OSPFv3 detailed database information fields (Continued)
This field... Displays...
