Multi-Service IronWare Routing Configuration Guide

343

53-1003033-02

Policy-based routing support for preserve VLAN

Output examples
The following example shows the output of the show telemetry rule-name command.

Brocade(config#) show telemetry rule-name

Paths with leading * are configured but disabled, entries with + is for IPv6

Route-map ACL Output Output

Rule Name Input Policy Match VLAN Port(s)

*test-traffic N/A Testing TestACL N/A N/A

*xGW_path1 N/A other_map xGW_Filter2 N/A N/A

xGW_path1 10/1 10/2 xGW_map xGW_Filter1 2 N/A

xGW_path1 +10/1 xGW_map xGW_Filter1 2 N/A

xGW_path2 10/1 10/2 xGW_map xGW_Filter2 None 4/1

xGW_path2 +10/1 xGW_map None 4/1

show telemetry rule-name test_traffic

Paths with leading * are configured but disabled, entries with + is for IPv6

Route-map ACL Output Output

Rule Name Input Policy Match VLAN Port(s)

*test-traffic N/A TestMap TestACL N/A N/A

The following example shows the output of the show telemetry detail rule-name command.

Brocade(config#) show telemetry detail rule-name

Rule name: test-traffic (disabled)

Input: None

Route-map Policy: Testing

IPv4 ACL match: Test_filter1

Output: None

Rule Name: xGW_Path1

Input: IPv4 - 10/1 10/2 IPv6 - 10/1

Route-map Policy: xGW_map

IPv4 ACL match: xGW_Filter1

IPv6 ACL match: xGW_Filter1

Output: IPv4 - VLAN 2 IPv6 - VLAN 2

Rule Name: xGW_Path2

Input: IPv4 - 10/1, 10/2 IPv6 - 10/1

Route-map Policy: xGW_map

IPv4 ACL match: xGW_Filter2

Output: IPv4 - 2/2 4/1 IPv6 - 2/2 4/1

Policy-based routing support for preserve VLAN

NOTE

Policy-based routing support for preserve VLAN is supported only on Brocade NetIron XMR and
Brocade MLX Series routers. This feature is now supported on the BR-MLX-10GX24 module.

Previously, PBR transparent VLAN flooding (TVF) replaced the ingress traffic’s VLAN ID with the
egress TVF VLAN ID, while flooding the egress TVF VLAN. Policy-based routing support for preserve
VLAN allows the ingress packet VLAN header (VLAN ID and priority) to be preserved, while
simultaneously flooding the PBR TVF VLAN.
