354 Multi-Service IronWare Routing Configuration Guide
53-1003033-02
Displaying MBGP information
The following sections show examples of some of the MBGP show commands. An example of the
show ip mroute and the show ipv6 mroute commands are also included. Both of the commands
display the multicast route table.
Displaying summary MBGP information
To display a summary of MBGP IPv4 information, enter the following command at any CLI prompt.
Syntax: show ip mbgp summary
NOTE
This command’s display looks similar to the display for the show ip bgp config command. However,
the show ip mbgp config command lists only the MBGP neighbors, whereas the show ip bgp config
command lists only the BGP neighbors.
To display a summary of MBGP IPv6 information, enter the following command at any CLI prompt.
Syntax: show ipv6 mbgp summary
Displaying the active MBGP configuration
To display the active MBGP IPv4 configuration information contained in the running-config without
displaying the entire running-config, enter the following command at any level of the CLI.
show ipv6 mbgp flap-statistics Displays route flap dampening statistics.
show ipv6 mbgp filtered-routes Displays routes that have been filtered out.
TABLE 59 MBGP show commands for IPv6 (Continued)
Command Description
Brocade# show ip mbgp summary
BGP4 Summary
Router ID: 10.9.9.1 Local AS Number : 200
Confederation Identifier : not configured
Confederation Peers:
Maximum Number of Paths Supported for Load Sharing : 1
Number of Neighbors Configured : 1, UP: 1
Number of Routes Installed : 5677
Number of Routes Advertising to All Neighbors : 5673
Number of Attribute Entries Installed : 3
Neighbor Address AS# State Time Rt:Accepted Filtered Sent ToSend
10.1.1.2 200 ESTAB 0h24m54s 3 0 5673 0
Brocade# show ipv6 mbgp summary
BGP4 Summary
Router ID: 10.1.1.1 Local AS Number: 100
Confederation Identifier: not configured
Confederation Peers:
Maximum Number of IP ECMP Paths Supported for Load Sharing: 1
Number of Neighbors Configured: 1, UP: 1
Number of Routes Installed: 4, Uses 344 bytes
Number of Routes Advertising to All Neighbors: 7, Uses 308 bytes
Number of Attribute Entries Installed: 2, Uses 184 bytes
Neighbor Address AS# State Time Rt:Accepted Filtered Sent ToSend
2001:db8::2 200 ESTAB 0h39m50s 4 0 3 0
