234

Multi-Service IronWare Routing Configuration Guide

53-1003033-02

Displaying OSPF information

Brocade# show ip ospf interface 192.168.1.1

Ethernet 2/1,OSPF enabled

IP Address 192.168.1.1, Area 0

OSPF state ptr2ptr, Pri 1, Cost 1, Options 2, Type pt-2-pt Events 1

Timers(sec): Transit 1, Retrans 5, Hello 10, Dead 40

DR: Router ID 0.0.0.0 Interface Address 0.0.0.0

BDR: Router ID 0.0.0.0 Interface Address 0.0.0.0

Neighbor Count = 0, Adjacent Neighbor Count= 1

Neighbor: 10.2.2.2

Authentication-Key:None

MD5 Authentication: Key None, Key-Id None, Auth-change-wait-time 300

Syntax: show ip ospf interface [ip-addr]

The ip-addr parameter displays the OSPF interface information for the specified IP address.

The following table defines the highlighted fields shown in the above example output of the show ip
ospf interface command

TABLE 34

Output of the show ip ospf interface command

This field

Displays

IP Address

The IP address of the interface.

OSPF state

The OSPF state of the interface.

Pri

The router priority.

Cost

The configured output cost for the interface.

Options

OSPF Options (Bit7 - Bit0):

unused:1

opaque:1

summary:1

dont_propagate:1

nssa:1

multicast:1

externals:1

tos:1

Type

The area type, which can be one of the following:

Broadcast = 0x01

NBMA = 0x02

Point to Point = 0x03

Virtual Link = 0x04

Point to Multipoint = 0x05

Events

OSPF Interface Event:

Interface_Up = 0x00

Wait_Timer = 0x01

Backup_Seen = 0x02

Neighbor_Change = 0x03

Loop_Indication = 0x04

Unloop_Indication = 0x05

Interface_Down = 0x06

Interface_Passive = 0x07

Adjacent Neighbor Count

The number of adjacent neighbor routers.

Neighbor:

The IP address of the neighbor.
