Multi-Service IronWare Routing Configuration Guide
561
53-1003033-02
Displaying BGP4+ information
This display shows the following information.
TABLE 115
Detailed route information received from a BGP4+ neighbor
This field...
Displays...
Number of BGP4+ routes
received from a neighbor
For information about this field, refer to
Status codes
For information about this field, refer to
Prefix
For information about this field, refer to
Status
For information about this field, refer to
Age
The age of the route, in seconds.
Next hop
The next-hop router for reaching the route from the device.
Learned from peer
The IPv6 address of the neighbor from which this route is learned. “Local
Router” indicates that the device itself learned the route.
Local pref
For information about this field, refer to
MED
The value of the route’s MED attribute. If the route does not have a metric, this
field is blank.
Origin
The source of the route information. The origin can be one of the following:
•
EGP – The routes with this set of attributes came to BGP4+ through EGP.
•
IGP – The routes with this set of attributes came to BGP4+ through IGP.
•
INCOMPLETE – The routes came from an origin other than one of the
above. For example, they may have been redistributed from OSPFv3 or
RIPng.
When BGP4+ compares multiple routes to a destination to select the best
route, IGP is preferred over EGP and both are preferred over INCOMPLETE.
Weight
For information about this field, refer to
AS Path
For information about this field, refer to
Brocade# show ipv6 bgp neighbor 2001:db8:1::1 received-routes detail
There are 4 received routes from neighbor 2001:db8:1::1
Searching for matching routes, use ^C to quit...
Status A:AGGREGATE B:BEST b:NOT-INSTALLED-BEST C:CONFED_EBGP D:DAMPED
E:EBGP H:HISTORY I:IBGP L:LOCAL M:MULTIPATH S:SUPPRESSED F:FILTERED
1 Prefix: 2001:db8:1000:1::/64, Status: BI, Age: 0h17m25s
NEXT_HOP: 2001:db8:1::1, Learned from Peer: 2001:db8:1::1 (100)
LOCAL_PREF: 100, MED: 0, ORIGIN: incomplete, Weight: 0
AS_PATH:
Adj_RIB_out count: 1, Admin distance 200
2 Prefix: 2001:db8:1::/64, Status: I, Age: 0h17m25s
NEXT_HOP: 2001:db8:1::1, Learned from Peer: 2001:db8:1::1 (100)
LOCAL_PREF: 100, MED: 0, ORIGIN: incomplete, Weight: 0
AS_PATH:
3 Prefix: 2001:db8:11::1/128, Status: BI, Age: 0h17m25s
NEXT_HOP: 2001:db8:1::1, Learned from Peer: 2001:db8:1::1 (100)
LOCAL_PREF: 100, MED: 0, ORIGIN: igp, Weight: 0
AS_PATH:
Adj_RIB_out count: 1, Admin distance 200
4 Prefix: 2001:db8:17::/64, Status: BI, Age: 0h17m25s
NEXT_HOP: 2001:db8:1::1, Learned from Peer: 2001:db8:1::1 (100)
LOCAL_PREF: 100, MED: 0, ORIGIN: incomplete, Weight: 0
AS_PATH:
Adj_RIB_out count: 1, Admin distance 200
