Multi-Service IronWare Routing Configuration Guide 687
53-1003033-02
Displaying OSPFv3 information
These displays show the following information.
Displaying OSPFv3 SPF information
You can display the following OSPFv3 SPF information:
• SPF node information for a specified area.
• SPF table for a specified area.
• SPF tree for a specified area.
TABLE 141 OSPFv3 route information
This field... Displays...
Current Route Count (Displays
with the entire OSPFv3 route
table only) The number of route entries currently in the OSPFv3 route table.
Intra/Inter/External
(Type1/Type2) (Displays with the
entire OSPFv3 route table only) The breakdown of the current route entries into the following route types:
•
Inter – The number of routes that pass into another area.
•
Intra – The number of routes that are within the local area.
•
External1 – The number of type 1 external routes.
•
External2 – The number of type 2 external routes.
Equal-cost multi-path (Displays
with the entire OSPFv3 route
table only) The number of equal-cost routes to the same destination in the OSPFv3 route
table. If load sharing is enabled, the router equally distributes traffic among the
routes.
Destination The IPv6 prefixes of destination networks to which the device can forward IPv6
packets. “*IA” indicates the next router is an intra-area router.
Cost The type 1 cost of this route.
E2 Cost The type 2 cost of this route.
Tag The route tag for this route.
Flags Flags associated with this route.
Dis Administrative Distance for this route.
Next-Hop Router The IPv6 address of the next router a packet must traverse to reach a
destination.
Outgoing Interface The router interface through which a packet must traverse to reach the
next-hop router.
Adv_Router The IP address of the advertising router.
Brocade# show ipv6 ospf route 2000::
Destination Cost E2Cost Tag Flags Dis
IA 2000::/64 1 0 0 00000003 110
Next_Hop_Router Outgoing_Interface Adv_Router
:: eth 1/1 10.1.1.1
