Displaying OSPF information
The displayed information shows the following:
Displaying OSPF area information
To display OSPF area information, enter the following command at any CLI level.
Syntax: show ip ospf area [area-id] | [num]
The area-id parameter shows information for the specified area.
The num parameter displays the entry that corresponds to the entry number you
enterShepherdshe entry number identifies the entry’s position in the area table.
This display shows the following information.
TABLE 23 CLI display of show tasks
This field... Displays...
Task Name Name of task running on the device.
Pri Priority of the task in comparison to other tasks
State Current state of the task
PC current instruction for the task
Stack Stack location for the task
Size Stack size of the task
CPU Usage(%) Percentage of the CPU being used by the task
task id Task’s ID number assigned by the operating system.
task vid A memory domain ID.
TABLE 24 CLI display of OSPF area information
This field... Displays...
Index The row number of the entry in the router’s OSPF area table.
Area The area number.
Type The area type, which can be one of the following:
•
nssa
•
normal
•
stub
Cost The area’s cost.
SPFR The SPFR value.
ABR The ABR number.
ASBR The ABSR number.
Brocade# show ip ospf area
Indx Area Type Cost SPFR ABR ASBR LSA Chksum(Hex)
1 0.0.0.0 normal 0 1 0 0 1 0000781f
2 10.147.60.0 normal 0 1 0 0 1 0000fee6
3 10.147.80.0 stub 1 1 0 0 2 000181cd
