Displaying IPv4 IS-IS information
Displaying LSP database entries
Use the following methods to display summary or detailed information about the entries in the LSP
database.
NOTE
The Brocade device maintains separate LSP databases for Level-1 LSPs and Level-2 LSPs.
Displaying summary information
To display summary information for all the LSPs in the Brocade device’s LSP databases, enter the
following command at any level of the CLI.
The command in this example shows information for the LSPS in the Brocade device’s Level-1 and
Level-2 LSP databases. Notice that the display groups the Level-1 and Level-2 LSPs separately.
Syntax: show isis database [lsp-id | detail | l1 | l2 | level1 | level2]
The lsp-id parameter displays summary information about a particular LSP. Specify an LSPID for
which you want to display information in HHHH.HHHH.HHHH.HH-HH format, for example,
3333.3333.3333.00-00. You can also enter name.HH-HH, for example, XMR.00-00.
The detail parameter displays detailed information about the LSPs. Refer to “Displaying detailed
information” on page 304.
Tag The tag value associated with the route.
Path The path number in the table. The IS-IS route table can contain multiple
equal-cost paths to the same destination, in which case the paths are
numbered consecutively. When IP load sharing is enabled, the Brocade
device can load balance traffic to the destination across the multiple
paths.
Next Hop IP The IP address of the next-hop interface to the destination.
Interface The Brocade device interface (port or virtual interface) attached to the
next hop.
Flags Values used by Brocade technical support for troubleshooting.
TABLE 43 IS-IS route information (Continued)
This field... Displays...
Brocade)# show isis database
IS-IS Level-1 Link State Database
LSPID LSP Seq Num LSP Checksum LSP Holdtime ATT/P/OL
XMR-1.00-00 0x0000000c 0xd048 963 1/0/0
XMR-1.01-00 0x00000004 0x09b0 957 0/0/0
XMR-1.02-00 0x00000001 0xc57b 961 0/0/0
XMR.00-00* 0x0000000b 0x23fb 1030 1/0/0
IS-IS Level-2 Link State Database
LSPID LSP Seq Num LSP Checksum LSP Holdtime ATT/P/OL
XMR-1.00-00 0x0000000d 0x7d97 964 1/0/0
XMR-1.01-00 0x00000004 0x09b0 958 0/0/0
XMR-1.02-00 0x00000001 0x200f 962 0/0/0
XMR.00-00* 0x0000000b 0x5647 1030 1/0/0
0000.0100.0003.00-00 0x0000001f 0x761a 932 0/0/0
0000.0100.0003.00-01 0x0000001d 0x9c9d 606 0/0/0
