802 Multi-Service IronWare Routing Configuration Guide
53-1003033-02
Displaying VRRP and VRRP-E information for IPv4
Displaying detailed information
To display detailed information for IPv4 VRRP or VRRP-E, enter the following command at any level
of the CLI.
Syntax: show ip vrrp
Syntax: show ip vrrp-extended
This display shows the following information.
Backup addr The IP addresses of the router interfaces that are currently Backups for
the virtual router.
VIP The virtual IP address that is being backed up by the virtual router.
TABLE 172 CLI display of VRRP or VRRP-E detailed information
This field... Displays...
Total number of VRRP (or
VRRP-Extended) routers defined The total number of virtual routers configured on this Brocade device.
NOTE: The total applies only to the protocol the Brocade device is
running. For example, if the Brocade device is running VRRP-E,
the total applies only to VRRP-E routers.
Interface parameters
Interface The interface on which VRRP or VRRP-E is configured. If VRRP or VRRP-E
is configured on multiple interfaces, information for each interface is
listed separately.
auth-type The authentication type enabled on the interface.
TABLE 171 CLI display of VRRP or VRRP-E summary information (Continued)
This field... Displays...
Brocade(config)# show ip vrrp-extended
Total number of vrrp-extended routers defined: 1
Interface v10
----------------
auth-type no authentication
VRID 10 (index 1)
interface v10
state backup
administrative-status enabled
mode non-owner(backup)
virtual mac 02e0.52a0.c00a
priority 50
current priority 50
track-priority 5
hello-interval 1 sec
backup hello-interval 60 sec
slow-start timer (configured) 30 sec
advertise backup disabled
dead-interval 3600 ms
preempt-mode true
virtual ip address 10.10.10.254
next hello sent in 1000ms
track-port 1/1 (up)
master router 10.10.10.4 expires in 3.1 sec
short-path-forwarding enabled
