Displaying BGP4 information
This display shows the following information.
TABLE 7
BGP4 summary information
This field...
Displays...
Router ID
The device’s device ID.
Local AS Number
The BGP4 AS number for the device.
Confederation Identifier
The AS number of the confederation in which the device resides.
Confederation Peers
The numbers of the local ASs contained in the confederation. This list
matches the confederation peer list you configure on the device.
Maximum Number of Paths
Supported for Load Sharing
The maximum number of route paths across which the device can balance
traffic to the same destination. The feature is enabled by default but the
default number of paths is 1. You can increase the number from 2 – 8 paths.
Refer to
“Configuring BGP4 multipath load sharing”
Number of Neighbors Configured
The number of BGP4 neighbors configured on this device, and currently in
established state.
Number of Routes Installed
The number of BGP4 routes in the device BGP4 route table and the route or
path memory usage.
Number of Routes Advertising to
All Neighbors
The total of the RtSent and RtToSend columns for all neighbors, the total
number of unique ribout group entries, and the amount of memory used by
these groups.
Number of Attribute Entries
Installed
The number of BGP4 route-attribute entries in the device route-attributes
table and the amount of memory used by these entries. To display the
route-attribute table, refer to
“Displaying BGP4 route-attribute entries”
Neighbor Address
The IP addresses of the BGP4 neighbors for this device.
AS#
The AS number.
