Using the Encryption Targets dialog box
20
Using the Encryption Targets dialog box
The Encryption Targets dialog box enables you to send outbound data that you want to store as
ciphertext to an encryption device. The encryption target acts as a virtual target when receiving
data from a host, and as a virtual initiator when writing the encrypted data to storage.
NOTE
The Encryption Targets dialog box enables you to launch a variety of wizards and other related
dialog boxes.
To access the Encryption Targets dialog box, complete the following steps.
1. Select Configure > Encryption from the menu task bar to display the Encryption Center
dialog box. (Refer to Figure 196 on page 566.)
2. Select a group, switch, or engine from the Encryption Center Devices table, then select
Group/Switch/Engine > Targets from the menu task bar.
NOTE
You can also select a group, switch, or engine from the Encryption Center Devices table, then
click the Targets icon.
The Encryption Targets dialog box displays. (Refer to Figure 331 .) The targets currently being
encrypted by the selected group, switch, or encryption engine are listed. If a group is selected,
all configured targets in the group are displayed. If a switch is selected, all configured targets
for the switch are displayed.
FIGURE 331 Encryption Targets dialog box
