The options are incremental from the last 30 minutes to the last 24 hours.
5. (Historical graphs and monitors only) Select the Plot Min/Max check box to plot minimum and
maximum values along with the average data point.
The range between the minimum and maximum values will be represented in a color band
surrounding the data points. The width of the color band indicates the variation during the time
period. Note that this option is not available if you select Minimum Interval granularity.
6. (Historical graphs and monitors only) Select one of the following options from the Granularity
list to set the granularity of the data point to display on the graph:
•
5 minutes
•
30 minutes
•
2 hours
•
1 day
NOTE
The graph will not update dynamically if the granularity is 30 Minutes, 2 Hours, or 1 day. To
update, move from one granularity setting to another. The graph will update dynamically when
Minimum interval is selected.
7. Select the Events check box to display advanced monitoring service (AMS) violation events
received during the chart time range.
8. (Real Time Graphs/Tables and Historical Graphs/Tables dialog boxes only) Click Publish to
create a performance monitor on the dashboard. For instructions, refer to
monitor from a performance graph”
Configuring graph options
Use the following steps to configure graph options for Real Time Performance Graph display as well
as time series monitors on the Dashboard tab or Performance Dashboard.
1. Click Options on the graph.
The Graph Options dialog box displays, as shown in
Figure 429
on page 1008.
