1048 Brocade Network Advisor SAN User Manual
53-1002948-01
Accessing Flow Vision from other management application features
30
NOTE
Entering * uses all values available devices from the ellipses button on the right of the Source
Device and Destination Device field.
For more information on using Bottleneck Detection, refer to “Bottleneck detection” on page 991.
Trace route and ping
Select an row from the Forward Route, Reverse Route, and FC Ping tabs on the Trace Route
Summary dialog box and select Add Flow to launch the Add Flow Definition dialog box. Use the Add
Flow Definition dialog box to configure and monitor flows established by your selections on the
Trace Route Summary dialog box. For more information on accessing and using trace route and
ping on the Trace Route Summary dialog box, refer to
“Tracing FC routes” on page 950.
If rows are not selected on the Trace Route Summary dialog box, the Add Flow Definition dialog box
is populated with the following information when available:
• Source Device - Source ID for ingress port
• Destination Device - Destination ID for egress port
• Target Switch - Switch for ingress port
• Direction - Bidirectional
If you select a row on the FC Ping tab the Add Flow Definition dialog box is populated with the
following information when available:
• Source Device - Source ID
• Destination Device - Destination ID
• Target Switch - Switch for source WWN
• Direction - Bidirectional
Table 98 describes how options are populated on the Add Flow Definition dialog box are populated
according to the row selected on the Forward Route tab.
TABLE 98 Add Flow Definition dialog box options populated per Forward Route row selection
Row Selected Options populated
No rows
selected Source Device = Source ID from source device port
Destination Device = Destination ID from destination device port.
Target Switch = Switch in selected row.
Direction = Bidirectional
