Brocade Network Advisor SAN User Manual 1419
53-1002948-01
Database tables and fields
H
TABLE 182 LICENSED_FEATURE
Field Definition Format Size
ID* Unique generated database identifier. int
NAME License feature name, a short text description. varchar 64
DESCRIPTION Optional detailed description about the license
feature. varchar 256
TABLE 183 LINK
Field Definition Format Size
LINK_ID Unique database generated identifier. int
TYPE Type of the link. Currently it is always U. varchar 1
NAME Name of the link which is combination of device
display name and ifName of the interface which this
link associated. varchar 255
TABLE 184 LOCK
Field Definition Format Size
NAME The name of this transaction synchronization lock. The
name should be upper case and should describe the
activity being synchronized, such as
MANAGED_ELEMENT_CREATION. varchar 40
LAST_USED_BY Identifies the transaction that last updated this lock
record, such as IP_DISCOVERY. This field is primarily
here just to have something to modify. The new value
does not need to be different than the previous value. varchar 40
LAST_USED_TIME Optional time when the lock was last modified. Might
be useful for debugging someday. timestamp
TABLE 185 LSAN_DEVICE
Field Definition Format Size
ID* Unique generated database identifier. int
BB_FABRIC_ID Backbone fabric DB ID. int
FCR_FABRIC_ID FID assigned to edge fabric. int
DEVICE_PORT_WWN Device port WWN of physical device. char 23
PHYSICAL_PID PID of physical device. char 6
TABLE 186 LSAN_TAG_CONFIG
Field Definition Format Size
ID* Unique id for FCR LSAN Tags configuration int
VIRTUAL_SWITCH_ID Database identifier of virtual switch which represent
FC Router. int
