Brocade Network Advisor SAN User Manual

53-1002948-01

Accessing Flow Vision from other management application features

Access Flow Vision features through the following management application features:

•

Frame Viewer

•

Bottleneck detection

•

Fibre Channel trace route, ping, and port connectivity troubleshooting features.

Frame Viewer

Select a frame from the Discarded Frames dialog box for a device or port and select Add Flow to
launch the Add Flow Definition dialog box. The Add Flow Definition dialog box will be populated with
the following information when available:

•

Source Device - Source ID

•

Destination Device - Destination ID

•

Ingress port - Transmit port

•

Egress Port - Receive port

•

Monitor - Bidirectional

NOTE

If the source or destination ID are not available, the source and destination device fields will contain
asterisks if the target switch supports learning.

Fixed value or
Not specified

Fixed value

Not specified Fixed value or

Not specified

Fixed value

Not specified Ingress port is only

available on 16
Gbps-capable Fibre
Channel platforms.
Frame Type is supported
without source device or
destination device values.

Fixed value or
Not specified

Not specified Fixed value

Fixed value or
Not specified

Fixed value

Not specified Frame Type is supported

without using source
device or destination
device

Fixed value

Not specified Fixed value

Not specified Not specified LUN monitor without Frame

Type needs both source
device and destination
device values
(ASIC limitation)

Fixed value

Not specified Fixed value

Fixed value

Not specified Not specified LUN monitor without Frame

Type needs both source
device and destination
device values
(ASIC limitation)

TABLE 96

Flow parameter combinations for Flow Monitor

Source
Device

Destination
Device

Ingress Port

Egress Port

LUN IDs

Frame Type

Bidirectional

Description/ Notes
